This is a list of all of the problems encountered with
the University of Iowa's PDP-8 computer.
Problems are numbered sequentially in the order of discovery.
Click on any thumbnail image to see the full-sized image.
The plastic switch handles at the left end of the row of switches are
chipped, as if they collided with something. They feel loose, and it
is probable that the plastic ears that hinge some of these switch handles
to their switches have broken. Some of the switches may also need
rebuilding, as we did with Bug 44.
|
| Loose cards
|
|---|
There are 8 card-edge connectors facing to the front on the side of the black
box holding the core memory. All but one of the circuit cards that
should be plugged into these connectors have fallen out.
|
| Right side
|
|---|
The front posts of the racks have aluminum channels holding plastic
foam weatherstrip against the cabinet skins. Whatever its purpose,
the foam in these channels has decayed.
It is brittle, and it crumbles when disturbed.
We will have to replace it with something less problematic.
The problem is similar to Bug 11, involving a foam
strip in an aluminum channel, but the dimensions are different.
|
| Cable Assembly
|
|---|
|
| Cable Connector
|
|---|
The ribbon cable assemblies that connect the left and right
half-backplanes of the machine are severely decayed.
The insulating layer on the two flex-print cable sthat make up each cable
assembly have turned to goo. We should find
an appropriate replacement material.
When the front panel with its lights and switches and the
entire computer is slid forward on its rack slides, the power supply and
rack are just barely balanced. The risk of the whole thing falling
over is significant.
- Noted Oct. 24, 2013.
- Noted Oct. 25, 2013.
Option of stabilizing leg(s) on attached table-top noted.
- Noted Oct. 28, 2013.
Note that the rack has leveling feet on the corners that have
a wider stance than the casters. These alone might suffice.
- Mitigated Jan. 23, 2014.
Leveling feet lowered to take weight off casters.
This provides only a small margin of safety when the computer
is extended from the rack!
- Solved temporarily
Feb. 05, 2014.
A wooden prop was made to support the weight of the fully
extended computer while the rack sides are removed for
access to the power supply. Replacing the table that was
formerly under the computer and had stabilizing feet would
be a better solution.
- Progress Mar. 26, 2015.
The table originally on this PDP-8 resembles (but is smaller than)
the table on the surviving PDP-7 at the Living Computer Museum.
We got photos from them documenting the construction of that table.
- Progress Sep. 27, 2019.
The Computer History Museum in Mountain View has a table from
a table-top PDP-8. They took extensive measurements of this table
for us. We suspect that the rack-mount table we need used most of
the same dimensions.
- Progress Oct. 29, 2024.
Plans for reconstructing the table prepared.
|
| The latch
|
|---|
The latch that holds the half-backplanes of the computer in their
closed positions is very difficult to turn. The key is in the latch
in the photo.
The solution is to grasp the frames for the two half backplanes near the
lock with one hand and squeeze them together while turning the key
with the other hand. This releases the friction on the latch making it
easy to turn.
|
|
| Broken reader
|
|---|
|
|
| Repair in progress
|
|---|
The paper-tape reader on the Teletype was broken.
The cast ears that attached the frame of the paper tape reader
to the frame of the Teletype broke off, probably when someone used
paper-tape reader as a handle to move the Teletype. Fortunately, these
could be replaced with home-made brackets. Also, the control lever
on the paper-tape reader was broken, probably in the same accident.
- Noted Oct. 25, 2013.
- Noted Nov. 25, 2013; plastic
covers and frame casting removed from reader.
- Noted Dec. 12, 2013; frame casting
taken home for repair.
- Partially resolved Dec. 16, 2013;
home-fabricated angle brackets added to replace broken ears on frame
casting, the frame casting was re-installed on the Teletype.
- Progress Jan. 7, 2014;
reader re-installed on frame casting. Note that reader control
lever is broken; can we glue it?
- Progress Feb. 19, 2014;
replaced broken reader control lever with new one;
didn't finish reader reassembly.
- Solved? Feb. 20, 2014;
reader reassembled and mechanism tested.
|
|
Before and after
|
|---|
The electrical wires at the back of the Teletype were pulled out of their
strain reliefs and needed to be redone before anyone even thinks
about plugging it in. Also, there seems to be an extra data cable.
- Noted Oct. 25, 2013.
- Noted Nov. 4, 2013;
Bug 14 and Bug 15 should
be addressed at the same time.
- Partially resolved Nov. 25, 2013;
the power cord was carefully pushed back into its strain relief
and the unknown extra cable was folded up into the case.
The data cable remains in need of proper strain relief.
- Solved May. 1, 2014.
Repaired data cable installed with new strain relief.
Questions about extra data cable remain unresolved.
- Noted Sep. 9, 2014.
Created Bug 38; the extra cable is for a power supply.
|
|
| The old and replaced hammer
|
|---|
The rubber head on the Teletype print hammer was shot.
For many years, the standard fix among Teletype collectors has been
to replace the rubber with a piece of vinyl tubing, but recently,
a serious collector has manufactured new replacement hammer heads.
|
|
| Power supplies
|
|---|
The electrolytic capacitors in the power supplies need reforming.
- Noted Oct. 28, 2013.
- Noted Jan. 23, 2014.
Necessary tools and supplies acquired.
- Noted Feb. 10, 2014.
Decided to remove and partially disassemble PDP-8 power supply,
creating Bug 20.
- Progress Feb. 11, 2014.
Removed PDP-8 power supply, began work reforming 10V capacitors.
- Noted Feb. 12, 2014.
10V capacitors reforming well.
- Noted Feb. 13, 2014.
10V capacitors reforming well.
- Progress Feb. 14, 2014.
10V capacitors reformed.
- Noted Feb. 17, 2014.
Begin work on -15V capacitors.
- Noted Feb. 18, 2014.
C9 to C11 reforming well.
- Noted Feb. 19, 2014;
C9 to C11 reforming well.
- Progress Feb. 20, 2014;
C9 to C11 reformed, begin work on C6 to C8.
- Noted Feb. 21, 2014;
C6 to C8 reforming well.
- Noted Feb. 24, 2014;
C6 to C8 reforming well.
- Noted Feb. 25, 2014;
C6 to C8 reforming well.
- Progress Feb. 26, 2014;
C6 to C8 reformed, begin work on C1 to C4.
- Noted Feb. 27, 2014;
C1 to C4 reforming well.
- Noted Feb. 28, 2014.
C1 to C4 reforming well.
- Noted Mar. 2, 2014.
C1 to C4 reforming well.
- Noted Mar. 3, 2014.
C1 to C4 reforming well.
- Noted Mar. 4, 2014.
C1 to C4 reforming well.
- Noted Mar. 5, 2014.
C1 to C4 reforming well.
- Progress Mar. 6, 2014.
C1 to C4 reformed, begin work on C5, C15 and C16.
- Noted Mar. 7, 2014.
C5, C15 and C16 reforming well.
- Noted Mar. 9, 2014.
C5, C15 and C16 reforming well.
- Noted Mar. 10, 2014.
C5, C15 and C16 reforming well.
- Progress Mar. 11, 2014.
C5 reformed, C15 and C16 reforming, but one may be bad.
- Noted Mar. 12, 2014.
- Noted Mar. 13, 2014.
C16 reforming, C15 confirmed bad.
- Progress Mar. 16, 2014.
C16 reformed, start work on capacitors in Teletype Call Control Unit.
- Noted Mar. 20, 2014.
TTY CCU caps reforming well, with replacement for C15.
- Noted Mar. 24, 2014.
TTY CCU cap reforming well, with replacement for C15.
- Partially solved Mar. 27, 2014.
TTY CCU cap and replacement for C15 reformed!
This completes the reforming of the capacitors
in the Teletype and PDP-8 power supply.
- Noted Apr. 30, 2014.
Extract Type 779 power supply for reforming,
creating Bug 32.
- Noted Sept. 9, 2014.
Capacitors C1 to C3 reforming.
- Noted Sept. 10, 2014.
Capacitors C1 to C3 held at 25V.
- Progress Sept. 18, 2014.
Capacitors C1 to C3 tested, not great but acceptable.
- Partially solved Oct. 2, 2014.
Capacitors C4 to C6 tested, not great but acceptable.
This completes the reforming of the capacitors
in the Type 779 power supply.
- Noted Nov. 14, 2014.
Start work on the capacitor in the Teletype tape-reader supply.
- Progress Dec. 1, 2014.
Change approach to the TR supply to get above 50 volts.
- Progress Dec. 3, 2014.
Reforming voltage idling at 125V.
- Progress Dec. 4, 2014.
Reforming voltage idling at 155V, but job only half done.
|
| Door gasket
|
|---|
The foam gaskets that seal the vertical edges of the rear plenum
door of each cabinet need renewal.
The problem is similar to Bug 3, involving a foam
strip in an aluminum channel, but the dimensions are different. Each door
has two gaskets, one on the latch side that is easy to see, and one on the
hinge side that is most apparent only when the door is open and the hinge-side
skin of the rack is removed.
|
| Tally reader cable
|
|---|
Where is the Tally reader interface that the card-edge connector on the
reader cable connects to? And, what slot in the reader interface?
As of the identification of this bug, the cable has been plugged into the
back of the Tally reader. Mapping of the 34D Scope display interface
revealed that this backplane segment at the bottom of the ADC rack includes
the high speed reader interface. Unfortunately, on further investigation,
it turned out that the cable, while it may have originally served this
reader, had been extensively modified and must be rebuilt.
|
| Dangling Jones plug
|
|---|
The 2-pin Jones plug on the back of the connector to the Tally paper tape
reader appears to be intended to bring power to the reader's drive motor.
Verify this, and then make the appropriate secondary cable to bring 110V power
from the power distribution panel on the ADC rack to this plug.
|
|
Cable repair
|
|---|
The Teletype data cable was cut between the W070 connector to the computer
and the 12-pin Jones plug at the back of the Teletype. The bad parts near the
ends of the cable were cut out and the salvaged remainder was reinstalled
with a 6-pin Jones plug at the point where the cable had been cut.
The resulting cable is shorter than the original, but with the jones plug
at the point of the cut, an extension cable can easily be added.
|
|
| Inappropriate plug
|
|---|
The 12-pin Jones plug in the Teletype cable was not really appropriate.
By 1970, DEC was using an 8-pin in-line Mate-n-Lok connector at this
point, but (as evidenced by the 12-pin connector here), earlier DEC users
who wanted a plug in their cables frequently used Jones plugs.
6-pin Jones plugs are still available, so we installed one.
- Noted Nov. 4, 2013, along with
Bug 8 and Bug 14.
- Noted Mar. 6, 2014.
New 6-pin Jones plugs acquired to replace 12-pin plugs.
- Noted Mar. 20, 2014.
Completed reverse engineering of cable, proposal for connector pinout.
- Progress Mar. 27, 2014.
Old connector discarded; start installing replacement.
- Solved May. 1, 2014.
New connector installed on cable to Teletype and W070 board.
|
| Cut power wires
|
|---|
The power distribution wiring harness between the ADC Rack and the PDP-8 rack
was cut, close to the terminal strip at the right rear corner of the rack.
The power cabling for the both racks will need careful checking.
- Noted Nov. 7, 2013.
The cut end on the ADC rack was identified.
- Noted Feb. 10, 2014.
The other side of the cut was located in the CPU cabinet
and coiled out of the way.
- Progress Apr. 4, 2014 A bad wire
on one of the cooling fans was cut out and replaced. The plug
on the PDP-8 line cord was declared unsafe.
- Progress Dec. 5, 2014.
We began work on the cable between the computer and ADC racks.
- Progress Jan. 23, 2015.
Start reverse engineering the Type 834 power control panel.
- Progress Jan. 27, 2015.
Mercury relay tested and documented.
- Progress Jan. 30, 2015.
Unsafe rack wiring documented.
- Solved? Jan. 30, 2015.
Wiring in PDP-8 rack fixed and tested,
creating Bug 43.
|
|
| Broken cover, start repair
|
|---|
|
|
| Repair completed
|
|---|
The transparent plastic insert in the Teletype cover was cracked and
entirely broken free
from its mounting. It appears that it was thermally riveted to the inside
of the cover. The whole cover was filthy, and
had a broken mounting ear. There are also cracks and broken mounting
fingers in other parts of the cover.
- Noted Nov. 25, 2013.
- Progress Feb. 21, 2014.
New window manufactured.
- Progress Feb. 24, 2014.
Started solvent-welding cracks and broken mounting
fingers in the ABS casing.
- Progress Feb. 25, 2014.
Reinforced previously glued cracks with ABS splints.
- Progress Feb. 27, 2014.
Replaced broken window-mounting studs in cover.
- Progress Mar. 2, 2014.
Rebuilt broken left rear mounting ear in cover.
- Progress Mar. 3, 2014.
Rebuilt mounting ear tested by mating cover with Teletype lid.
- Solved Mar. 13, 2014.
Permanently attached new window, installed lid in Teletype cover.
|
|
| ADC Plenum door
|
|---|
The rear plenum door of the ADC rack is missing one panel (the one below the
ADC interface panel) and about 20 screws. This admits dust and degrades the
effectiveness of the rack's cooling fan. A somewhat battered replacement
panel has been located -- original DEC manufacture, formerly part of PDP-9
serial number 120.
- Noted Dec. 12, 2013.
- Partially resolved Jan. 7, 2014;
the old PDP-9 panel was
patched and installed (temporarily with the wrong kind of screws).
- Solved Apr. 14, 2014;
missing screws replaced.
|
|
| Preliminary backplane maps
|
|---|
We need to inventory the boards in both backplanes, then remove them
and clean both the boards and the backplanes, and then re-insert the
boards where they came from. Wherever there are discrepancies between
the boards and the maintenance manuals, we will need to do more to figure
out how to put things right, suspecting boards might have been pulled and
replugged incorrectly over the years when this machine was not operational.
|
|
| The supply out of the rack
|
|---|
|
| Opened up for capacitor access
|
|---|
To allow reforming of the capacitors in the PDP-8 power supply
(see Bug 10),
the supply needed to be removed from the rack and partially disassembled.
- Problem created Feb. 10, 2014.
Wiring harness almost completely removed.
- Noted Feb. 11, 2014.
Supply moved to table.
- Further damage Feb. 13, 2014.
Rivets holding back panel to supply removed.
- Further damage Feb. 14, 2014.
Back panel eased out from side panels.
- Progress Feb. 17, 2014.
Installed swage nuts to replace pop-rivets.
- Progress Mar. 11, 2014.
Re-connected C5 and started reconnecting C6-11.
- Progress Mar. 16, 2014.
C6-11 and C16 reconnected.
- Progress Mar. 27, 2014.
New C15 installed, old C17 removed.
- Progress Apr. 4, 2014.
New C17 installed.
- Progress May 5, 2014.
Replacement power connector work begun.
- Solved? May 6, 2014.
Power supply reassembled and installed, creating
Bug 33.
- Reopened Oct. 29, 2014, power-OK
signal never asserted.
- Progress Nov. 12, 2014,
Transistors Q1 and Q2 verified good.
- Solved? Nov. 18, 2014,
Boards were in wrong slots!
|
|
| Decayed foam | New foam
|
|---|
The foam rubber pad under the typing unit was decayed and crumbled
when disturbed.
This is Teletype part number 181138, pad,
pages 25 (drawing) and 32 (parts list) in
Parts Model 32 and 33 Page Printer Set, Teletype Corp.
Bulletin 1184B, Nov. 1964, change 5.
|
| Decayed rubber
|
|---|
The rubber grommets that serve as vibration isolators were decayed and
crumbled when disturbed.
This is part number 181109, mount, vibration,
pages 25 (drawing) and 32 (parts list) in
Parts Model 32 and 33 Page Printer Set, Teletype Corp.
Bulletin 1184B, Nov. 1964, change 5.
|
|
| Base re-mounted
|
|---|
One teletype sub-base mounting bolt was missing.
and two more appear to have been inappropriate substitutes.
Two call control unit mounting screws were missing.
|
| The print head
|
|---|
The Teletype mechanism was dirty and the old oil and grease has congealed
to an adhesive gum. For example, the print head carriage bearings were
so thorougly gummed that they would not rotate at all before several soakings
in WD-40. Cleaning these parts requirede nearly complete disassembly
of the machine.
|
|
| Major subassemblies
|
|---|
Cleaning and de-gumming the Teletype required large-scale disassembly,
so we need to put it back together.
- Noted Feb. 11, 2014.
- Progress Mar. 7, 2014.
Keyboard reassembled, but needs lubrication.
- Progress Apr. 29, 2014.
Typing unit reassembly started.
- Progress Apr. 30, 2014.
Reassembly continues.
- Progress May. 12, 2014.
Typing unit reassembled.
- Progress Nov. 11, 2014.
Broke a screw, creating Bug 39.
- Progress Dec. 3, 2014.
Paper tape punch reattached to typing unit.
|
| Parts re-united
|
|---|
|
| Reassembled
|
|---|
- Progress Jan. 14, 2015;
All sub-base castings reunited and mounted on pedestal.
- Progress Jan. 29, 2015;
Rebuild keyboard contact block.
- Progress Feb. 02, 2015;
Keyboard reassembled and mounted to base.
- Progress Feb. 04, 2015;
Call Control Unit mounted and wired.
- Progress Feb. 16, 2015;
powered up, creating Bug 48,
Loose spring found.
- Progress Mar. 30, 2015;
Loose spring misidentified, keyboard fixed?
- Progress Apr. 2, 2015;
Loose spring correctly reinstalled.
- Progress Nov. 15, 2016.
Reassembled and lubricated ribbon mechanism.
- Progress Mar. 28, 2016.
Note status of reassembly.
- Solved! May 17, 2019.
Reassembly completed!
|
|
| The keyboard, before and after
|
|---|
The Teletype keyboard keys were in very bad shape. The outer grey
layer of many keys has almost shattered into multiple fragments that
are not strongly attached to the white core of each key. Zoom in on
the photo for details. Can we buy or make new keys? Consider the
keys here that were made with laser-engraved acrylic filled with contrasting
paint, then laser cut and laminated to build up the required depth.
We eventually found a source of new-old-stock keys and replaced the
worst of the bad ones.
|
|
| Tally capstan and take-up reel drive
|
|---|
The Tally 424 paper-tape reader mechanism needs to be properly lubricated.
This will require partial disassembly and reassembly of the reader.
|
|
| The capacitor and replacement
|
|---|
The Tally paper-tape reader motor uses a 3µF paper and oil capacitor.
Given the time period when this was made, it is almost certainly filled with
PCB oil and reports from others suggest that failures are not uncommon and
occasionally explosive. Therefore, it must be replaced.
|
| The motor stator
|
|---|
The power leads to the Tally paper-tape reader motor were in bad
conditon and needed replacement.
|
| Installing a rivnut
|
|---|
|
| Removing wiring
|
|---|
When the Psychology department mounted the Tally reader and magnetic tape
interface in spare spots in the ADC rack, they drilled out some of the rivnuts
DEC had installed and drilled (carelessly) some new holes. Before we
remount the Tally reader and any other peripherals in this rack, we should
replace the missing rivnuts. We will need to replace other missing parts of
this rack, and if we change the configuration of equipment in this rack,
we may need to add new rivnuts. We also need to remove the wiring and
electronics for the peripherals we no-longer have.
- Progress Apr. 29, 2014.
Missing rivnuts replaced.
- Progress May 5, 2014.
New doorstop for top front doors.
- Progress Feb 14, 2018.
Remove wiring for mag-tape drive.
- Progress Feb 21, 2018.
Remove bulk of mag-tape drive interface. Parts remain in row D of the ADC
interface.
|
The supply
|
|---|
In order to reform the capacitors in the Type 779 power supply, it
had to be extracted from the ADC rack.
- Problem created Apr. 30, 2014.
Extract Type 779 power supply for reforming.
- Progress Oct. 2, 2014.
Capacitors reformed, reassembly started.
- Solved Oct. 9, 2014.
Supply reassembled, tested and put back in the ADC rack.
|
|
| Test load
| 10V at 10A 300mV
|
|---|
With the capacitors reformed and the power supply reassembled, it is time
to test it. This involves constructing a dummy load and measuring all of
the outputs under this load.
The Tally paper tape reader interface is a subsystem of the
Type 34D Oscilloscope Display backplane.
DEC designed this interface as the Type 750C High Speed Reader, but that
interface appears to be designed for a photoelectric reader. There is
evidence of tinkering in the backplane here, so we need to thoroughly
understand what was done to make the DEC interface work with the Tally reader.
|
| Trimmer added
|
|---|
The Marginal Check power supply panel meter reads about 10% high compared
to the VOM used in power supply testing.
The Inhibit and Read/Write supplies do not work. These are regulated
supplies with outputs that only connect when both voltages are within spec.
A relay driver performs the logical and function.
|
| W982 Board
|
|---|
The Inhibit and Read/Write supplies do not work. These are regulated
supplies with outputs that only connect when both voltages are within spec.
A relay driver performs the logical and function.
|
| The Supply
|
|---|
The power supply for the Teletype mounts either on the Call Control Unit
or on in the Teletype pedestal. Our supply was missing, but we obtained a
broken one from eBay for a pittance. Unfortunately, it is broken, and it
came without a mounting bracket.
Teletype part-number 182891 is a very unusual screw. Unfortunately,
the fat screw head invites overtightening. Fortunately, the huge
screw head means that this screw can be repaired.
- Problem Created Nov. 11, 2014.
Overtightened screw breaks.
- Solved Dec. 1, 2014.
Old screw head drilled and tapped to hold a new screw body.
The sense amplifier in backplane slot MB30 was damaged during the
backplane inventory and cleaning (see
Bug 19). The repair was essentially straightforward.
- Problem noted Dec. 4, 2014.
Broken pin-connector socket for sense wire on handle-side of board.
- Solved Dec. 5, 2014.
Repaired using D-subminiature socket parts.
|
| Lugs replaced with screws
|
|---|
The cover over the Teletype keyboard was supported and aligned on 3 mounting
lugs, all of which have broken off.
|
|
| Original | Rebuilt
|
|---|
With the power supply tested and the rack wiring fixed, we can
turn on the computer. Now we must see if it works!
|
|
| Switch parts during cleaning
|
|---|
After turning on the computer, we found that power was not reaching
all parts of the PDP-8 backplane. The problem turned out to lie in the
switches that allow switching each row of the backplane from the primary
power supply to the variable voltage marginal-test power supply.
Repair or replacement of these switches is in order.
|
| Cleaning the fans
|
|---|
There was considerable dust on the bottoms of the 3 fans at the bottom of
each half backplane of the PDP-8, so we removed the fan blades from their
motors, cleaned everything, and then opened the motor hubs and oiled them.
| Front panel
To deal with Bug 1 and Bug 47,
we had to disassemble the PDP-8 front panel. It will need reassembly.
|
|
| The lamps. | All lamps lit!
|
|---|
When we began testing the PDP-8
(Bug 43)
we found that many of the bulbs on the
front panel did not light, although other evidence suggested that
the bulbs ought to light.
- Problem noted Feb. 11, 2015.
Front panel removed and opened up.
- Progress Feb. 17, 2015.
Got replacement lamps and reverse engineered lamp circuitry.
- Progress Feb. 23, 2015.
Replaced a total of 28 lamps, one remains inoperable, a bad transistor?
- Progress Apr. 3, 2015.
Open up front panel to gain access to transistor in question.
- Progress Apr. 6, 2015.
The problem was a bad circuit trace, not a bad transistor.
- Progress Apr. 9, 2015.
Three more lamps failed during front panel reassembly.
- Solved Apr. 13, 2015.
All lamps now light!
|
|
| First test | 11 weeks later
|
|---|
Having reassembled the Teletype, it is time to see how it works.
- Problem created Feb. 16, 2015;
it chatters away when it should be idling.
- Progress Oct. 14, 2015;
Created Bug 52, adjust the Teletype.
- Progress July 19, 2016;
Tape punch works but punches wrong data.
- Progress July 20, 2016;
Tape punch works, punches as typed.
- Progress Sep. 13, 2016;
Space, CR, LF, work, but types wrong letters.
- Progress Sep. 27, 2016;
Most letters print most of the time, but stutters.
- Progress Oct. 13, 2016;
M misprints as ←, and F, N, V and 6 misaligned.
- Progress Dec. 1, 2016;
S occasionally misprints as ←, T and I also problematic.
- Progress Dec. 8, 2016;
Pretty reliable, but occasional doubles and the bell rings too much.
- Progress Mar. 7, 2017;
Very reliable, but occasional problems with V and W at high speed.
|
| Testing the R211
|
|---|
The R211 boards are double-height boards.
Each hold one bit of the memory address, program counter
and memory data registers, plus the multiplexer logic for
loading those registers.
- Problem created Apr. 22, 2015;
The MA register on the board in slots PC8 and PD8 seems to be stuck on.
- Progress May 19, 2015;
Something got hot when the board was powered up.
created Bug 51.
- Progress May 22, 2015;
took board photos,
creating Bug 50.
- Progress June 8, 2015;
discovered that tests on May 19 may have damaged board.
- Progress June 24, 2015;
tests on May 19 appear to have done no harm.
- Progress July 2, 2015;
board testing points to bad transistor.
- Progress Sept. 30, 2015;
the problem was a bad diode.
- Problem reopened Apr. 6, 2017;
PC carry propagation problem observed,
see Bug 61.
- Progress Apr. 20, 2017;
Bad diode found, but a different bit will not load from switches.
|
|
| The R211 H board.
|
|
| The R211 H reverse engineered.
|
The R211 boards are extraordinarily complex double-height boards, where
relating components on the board to the schematic diagram is not easy.
The image showing the result of the reverse engineering shows both sides
of the board, superimposed (with traces on the solder-side shaded red).
The text gives part numbers; those prefixed with equals signs (=) reference the
1965 schematic
of the R211 H;
those without reference the
1966 schematic
of the R211 J.
Markings on vias relate them to pins on the card edge connector or to the
voltages distributed on that circuit trace.
- Problem created May 22, 2015;
took board photos to launch process.
- Progress June 8, 2015;
part numbers related to schematic diagrams.
- Solved June 17, 2015.
revision letters pinned down.
|
|
| Test fixture | Logic Probes
|
|---|
Testing boards from the PDP-8 is easier if they can be tested outside
the PDP-8 backplane. This required building a test rig and a logic test
probe.
- Problem created May 19, 2015;
built a preliminary test rig.
- Progress May 24, 2015;
added framework, on-off switches and pilot lights.
- Done? July 2, 2015;
built a pair of logic probes.
|
| Reader stop latch
|
|---|
|
| Adjusting platen height
|
|---|
There are numerous adjustments that must be made after disassembling and
reassembling the Teletype.
- Problem created Oct 14, 2015;
adjusted universal lever and reader stop latch.
- Progress July 19, 2016;
can type to punch and typing unit, results are frequently wrong.
- Progress July 20, 2016;
"rangefinder" adjusted, punch reliably outputs what is typed.
- Progress Sep. 27, 2016;
Correctly types most of the time, but stutters.
- Progress Oct. 13, 2016;
Fixed stutter in function clutch (release needed adjusting).
- Progress Nov. 15, 2016;
Fixed tension on selector magnet armature.
- Progress Dec. 1, 2016;
Adjusted selector armature, rear carriage rail height.
- Progress Dec. 8, 2016;
Selector armature, print hammer trip lever, distributor trip linkage.
- Progress Feb. 2, 2017;
Adjust paper-tape punch penetration.
- Progress June. 22, 2017;
Adjust platen height and type-drum centering.
- Progress June. 29, 2017;
Adjust line feed drive link and up stop.
- Progress June. 25, 2017;
Adjust platen height again.
|
| Missing felt washers
|
|---|
The outboard end of one of the pivot shafts in the Teletype is missing several
felt washers.
- Problem created Feb 17, 2016;
made new felt washers, installation looks wrong.
|
| Code bar bracket
|
|---|
The bracket that serves as an alignment comb at the left end of the code bars
that serve as the main mechanical data bus in the teletype was not attached.
Floating loose on the code bars, it did not seem to be doing any harm, but
it should be attached.
|
|
| Broken | Replaced
|
|---|
The carriage return lobe plate that mounts on the left side of the carriage
was broken. This prevents the spacing mechanism from working after a carriage
return because without it, the return lever stays latched, disengaging the
spacing pawls.
Most of the control-character actuating levers was not engaged properly
with the corresponding linkages, and the corresponding function levers were not
properly engaged with their function pawls.
- Problem created Aug. 12, 2016;
discovered the problem.
- Progress Sep. 8, 2016;
CR function lever now decodes, but no actuation.
- Progress Sep. 13, 2016;
CR seems to work correctly.
- Progress Nov. 15, 2016;
BEL and ENQ seem to work correctly, but testing fails.
During reassembly of the Teletype, the automatic codebar was inserted in the
wrong slot in the codebar assembly, causing the function bell to ring with
every character typed.
After enough of the Teletype was repaired that the typing mechanism began
working reasonably reliably, there were misprints that focused on incorrect
values of data bit 4.
- First evidence Oct. 13, 2016;
Looking back through the logs, the evicence of this problem
was first recognized and connected to bit 4.
- Problem created Mar. 7, 2016;
Bit 4 only converted from 0 to 1 after a 1,
and the problem is in the receiver.
- Diagnosis Mar. 23, 2016;
The selector armature is being locked prematurely in the on position.
- Solved Mar. 28, 2016;
A small rangefinder change fixes it!
The rubber of the teletype platen is very hard, limiting the print quality.
Is there some way to recondition it?
The back panel of the teletype stand is missing.
Can we manufacture a replica of the original?
When you increment the PC, carry does not propagate from PC bit 2 to bit 1.
This is most obvious when you hit RUN with the memory disabled so all fetches
get opcode zero (AND). The PC lights up as
00X XXX XXX XXX, where bulbs marked X are on
at half intensity because they are flickering between 0 and 1.
- Problem diagnosed Apr. 6, 2017;
Moving boards pins the problem on an R211 board,
reopening Bug 49.
- Progress Apr. 20, 2017;
Bad diode found, but a different bit will not load from switches.
|
|
|
| The screwdriver
| Adjusting LF drive link
|
|---|
We broke the linefeed mechanism while adjusting the platen height.
- Problem created June 22, 2017;
We left a screwdriver in the left platen height
pry point when we hit LF.
- Solved June 29, 2017;
Adjusting the line feed drive link and up stop compensated for
the bending or stretching caused by our error.
|
| The problem spring
|
|---|
The paper-tape reader only runs if the clutch-trip magnet's armature at the
rear of the Teletype is held down manually. This is evidence that there's
something wrong in the wiring of the reader-run circuit.
- Problem created Mar. 7, 2017;
need to hold down clutch-trip armature discovered.
- progress July 6, 2017;
documents identified that show this should not be needed.
- Solved July 11, 2017;
one contact spring in the reader was improperly reassembled.
|
|
| Inhibit and R/W select currents
|
|---|
Memory does not work.
- Problem observed in passing Apr. 6, 2017;
memory does not work.
- Problem observed again Nov. 17, 2017;
can get data to MB register, but it reads back as zero.
- no progress Feb. 12, 2018;
speculate that a W034 cable is missing.
- small progress Feb. 21, 2018;
found the memory current limiters.
- small progress Apr. 4, 2018;
added test points to simplify current probe.
- progress? Apr. 11, 2018;
preliminary current probe results.
- small progress Apr. 18, 2018;
useful current probe results.
- small progress Apr. 25, 2018;
check quality of power supply regulation.
- progress? May 2, 2018;
swapping regulators has no effect.
- progress? Sept. 13, 2018
Memory Strobe and Inhibit signals seem wrong.
- progress? Sept. 27, 2018
Study B360 board that generates memory stribe.
- progress? Nov. 8, 2018
Data tracked from the switch register to the Inhibit drivers.
- progress? Dec. 6, 2018
Strobe pulse may be shorted to ground by a sense amplifier.
- progress Mar 19, 2019
Reverse engineer G007 sense amplifier board.
- progress? May 17, 2019
Replace open diode in G007 sense amplifier.
- verified status unchanged, Jan 31, 2023
- found bug? Oct 9, 2024
Clock debugging.
- progress Oct 21, 2024
R603 reverse engineer and repair.
- progress Oct 28, 2024
Clock debugging.
- progress! Oct 30, 2024
All memory timing waveforms verified to be correct.
- progress! Nov 4, 2024
Memory current settings measured, close to correct.
- progress. Nov 13, 2024
Memory current and voltage settings set by the book.
|
|
We found that we needed to watch signals on the wire-wrapped backplane, so
we built logic probes.
We found that we could only achieve marginally acceptable static balance on
the G007 sense amplifier in slot MB27.
|
| MA11 and its inverse? |
|---|
We found noise on one of the memory address line MA11(0) with an amplitude
exceeding the signal amplitude. We will have to check all the memory address
lines.
